JV-1MD/JV-1FD/JV-DV/JV-DVF Operation Manual

Cleaning the inside of the nameplate cover (JV-DV only)



  1. Remove the front panel.
    Loosen the special screw with the included special screwdriver [A], and remove the front panel [B].


  2. Pull out the nameplate [C].


  3. Remove the nameplate cover [D].


    ATTENTION

    • Do not put a sticker over the nameplate cover. Otherwise the LED illumination for the nighttime is decreased.
    • Do not remove the packing. If the packing is not installed properly, water may enter the nameplate cover.



  4. Gently wipe the inside of the nameplate cover using a soft, dry cloth.
    For tough stains, use a lightly damp cloth and neutral detergent diluted in water.

  5. Insert the nameplate.

  6. Install the front panel in the opposite order of removal.
